MINI Series-12W Built-in ON/OFF LED Driver (CV)

Product Description

Super compact design for built-in use

Primary and secondary sides come with leads

Protections: opencircuit, shortcircuit, overload

DC input compatible (176-250Vdc)

Seal with glue

Suitable for protection class I & II luminaires


MINI Series-12W Built-in ON/OFF LED Driver (CV)

Product Family

Model
No.		Nominal
Voltage		Power
Factor		Max.
Output		Output
Voltage		Output
Curren		Efficiency
Full Load		Ambient
Temperature		Max. Case
Temperature		Dimensions
LxWxH
MINI-12-12220-240V0.90C12W12V0-1A78%-20...50°C85°C50x48x24mm
MINI-12-24220-240V0.90C12W24V0-0.5A80%-20...50°C85°C50x48x24mm
