LGM Series-30-50W Independent TRIAC Dimming

Product Description

Independent design

Dimmable with leading edge or trailing edge dimmer

Smooth dimming compatible with most dimmer

Dimming range from 1…100%

Configurable constant current output via DIP switch

Adjust color temperature via the CCT toggle switch (Optional)

Push wire connections

Protections: opencircuit, shortcircuit, overload, overtemperature

DC input compatible (176-280Vdc)

Suitable for protection class I&II luminaires

LGM Series-30-50W Independent TRIAC Dimming

Product Family

Model No.	Nominal Voltage	Power Factor	Max. Output	Output Current	Output Voltage	Efficiency Full Load	Ambient Temperature	Max. Case Temperature	Dimensions LxWxH
LGM-30T	220-240V	0.95	21W	500mA	21-42V	87%	-20...45℃	85℃	142x50x24mm
			25.2W	600mA	21-42V	87%	-20...45℃	85℃	142x50x24mm
			29.4W	700mA	21-42V	87%	-20...45℃	85℃	142x50x24mm
			30W	750mA	21-40V	87%	-20...45℃	85℃	142x50x24mm
LGM-40TL	220-240V	0.95	26W	500mA	26-52V	87%	-20...45℃	85℃	166x52x25mm
			31.2W	600mA	26-52V	87%	-20...45℃	85℃	166x52x25mm
			36.4W	700mA	26-52V	87%	-20...45℃	85℃	166x52x25mm
			40W	800mA	26-50V	87%	-20...45℃	85℃	166x52x25mm
LGM-40T	220-240V	0.95	29.4W	700mA	21-42V	87%	-20...45℃	85℃	166x52x25mm
			31.5W	750mA	21-42V	87%	-20...45℃	85℃	166x52x25mm
			36W	900mA	21-40V	87%	-20...45℃	85℃	166x52x25mm
			36.1W	950mA	21-38V	87%	-20...45℃	85℃	166x52x25mm
LGM-50TL	220-240V	0.95	44.2W	850mA	26-52V	88%	-20...45℃	90℃	166x52x25mm
			46.8W	900mA	26-52V	88%	-20...45℃	90℃	166x52x25mm
			49.4W	950mA	26-52V	88%	-20...45℃	90℃	166x52x25mm
			50.4W	1050mA	26-48V	87%	-20...45℃	90℃	166x52x25mm
LGM-50T	220-240V	0.95	42W	1000mA	21-42V	88%	-20...45℃	90℃	166x52x25mm
			44.1W	1050mA	21-42V	88%	-20...45℃	90℃	166x52x25mm
			48W	1200mA	21-40V	87%	-20...45℃	90℃	166x52x25mm
			50.7W	1300mA	21-39V	87%	-20...45℃	90℃	166x52x25mm
