CBU Series-20-100W ON/OFF LED Driver

Product Description

Modular 15.9mm ultra thin design, plug-and-play

Universal AC input (100-240Vac)

Featuring a C8 plug input and four output ports

Protections: opencircuit, shortcircuit, overload, overtemperature

DC input compatible (140-280Vdc)

Suitable for protection class I & II luminaires

Protection class II

CBU Series-20-100W ON/OFF LED Driver

Product Family

Model No.	Nominal Voltage	Power Factor	Max. Output	Output Voltage	Output Current	Efficiency Full Load	Ambient Temperature	Max. Case Temperature	Dimensions LxWxH
CBU-20-12	100-240V	0.95	20W	12V	0-1.67A	83%	-20...45℃	90℃	100x75x15.9mm
CBU-20-24	100-240V	0.95	20W	24V	0-0.84A	83%	-20...45℃	90℃	100x75x15.9mm
CBU-40-12	100-240V	0.95	40W	12V	0-3.33A	88%	-20...45℃	90℃	160x75x15.9mm
CBU-40-24	100-240V	0.95	40W	24V	0-1.67A	88%	-20...45℃	90℃	160x75x15.9mm
CBU-60-12	100-240V	0.95	60W	12V	0-5A	88%	-20...45℃	90℃	160x75x15.9mm
CBU-60-24	100-240V	0.95	60W	24V	0-2.5A	88%	-20...45℃	90℃	160x75x15.9mm
CBU-100-24	100-240V	0.95	100W	24V	0-4.17A	92%	-20...45℃	90℃	210x75x15.9mm
