LT-TW Series-75-240W DT8 DALI Dimming (CV)

Product Description

Independent super slim design (32x21.6mm cross section)

Support DALI DT8, Switch DIM and ColourSWITCH

ColourSWITCH with predefined colours

Dimming range 0.1...100%

Push wire connections

Protections: opencircuit, shortcircuit, overload, overtemperature

DC input compatible (176-280Vdc)

Suitable for protection class II luminaires

Protection class II

LT-TW Series-75-240W DT8 DALI Dimming (CV)

Product Family

Model No.	Nominal Voltage	Power Factor	Max. Output	Output Voltage	Output Current	Efficiency Full Load	Standby Power	Ambient Temperature	Max. Case Temperature	Dimensions LxWxH
LT-75-24D TW	220-240V	0.95	75W	24V	0.2-3.125A	91%	<0.5W	-20...50°C	80°C	400x32x21.6mm
LT-75-48D TW	220-240V	0.95	75W	48V	0.1-1.57A	91%	<0.5W	-20...50°C	80°C	400x32x21.6mm
LT-100-24D TW	220-240V	0.95	100W	24V	0.2-4.17A	90%	<0.5W	-20...50°C	85°C	400x32x21.6mm
LT-100-48D TW	220-240V	0.95	100W	48V	0.1-2.08A	90%	<0.5W	-20...50°C	85°C	400x32x21.6mm
LT-150-24D TW	220-240V	0.95	150W	24V	0.2-6.25A	91%	<0.5W	-20...45°C	90°C	400x32x21.6mm
LT-150-48D TW	220-240V	0.95	150W	48V	0.1-3.125A	91%	<0.5W	-20...45°C	90°C	400x32x21.6mm
LT-200-24D TW	220-240V	0.95	200W	24V	0.2-8.33A	92%	<0.5W	-20...45°C	90°C	450x32x23mm
LT-200-48D TW	220-240V	0.95	200W	48V	0.1-4.17A	91%	<0.5W	-20...45°C	90°C	450x32x23mm
LT-240-24D TW	220-240V	0.95	240W	24V	0.2-10A	91%	<0.5W	-20...45°C	90°C	450x32x23mm
LT-240-48D TW	220-240V	0.95	240W	48V	0.1-5A	92%	<0.5W	-20...45°C	90°C	450x32x23mm
