EUM TW Series-13-45W Independent DALI Dimming

Product Description

Independent screwless design

iDATA (DALI-2 part ext.251, 252 and 253)

Switch DIM and ColourSWITCH function

Corridor function application

Dimming range 0.1...100%

Configurable output current via DIP switch

Push wire connections

Protections: opencircuit, shortcircuit, overload, overtemperature

DC input compatible (176-250Vdc)

Suitable for protection class II luminaires

Protection class II

EUM TW Series-13-45W Independent DALI Dimming

Product Family

Model No.	Nominal Voltage	Power Factor	Max. Output	Output Current	Output Voltage	Efficiency Full Load	Standby Power	Ambient Temperature	Max. Case Temperature	Dimensions LxWxH
EUM-12D TW	220-240V	0.95	6.3W	150mA	2-42V	80%	<0.5W	-20...45℃	90℃	127x35x20mm
			8.4W	200mA	2-42V	82%	<0.5W	-20...45℃	90℃	127x35x20mm
			10.5W	250mA	2-42V	82%	<0.5W	-20...45℃	90℃	127x35x20mm
			12W	300mA	2-40V	83%	<0.5W	-20...45℃	90℃	127x35x20mm
			11.9W	350mA	2-34V	82%	<0.5W	-20...45℃	90℃	127x35x20mm
			12W	500mA	2-24V	81%	<0.5W	-20...45℃	90℃	127x35x20mm
			12W	600mA	2-20V	81%	<0.5W	-20...45℃	90℃	127x35x20mm
			11.9W	700mA	2-17V	80%	<0.5W	-20...45℃	90℃	127x35x20mm
EUM-13D TW	220-240V	0.95	6.3W	150mA	2-42V	80%	<0.5W	-20...45℃	90℃	127x35x20mm
			8.4W	200mA	2-42V	82%	<0.5W	-20...45℃	90℃	127x35x20mm
			10.5W	250mA	2-42V	83%	<0.5W	-20...45℃	90℃	127x35x20mm
			12.6W	300mA	2-42V	83%	<0.5W	-20...45℃	90℃	127x35x20mm
			13.3W	350mA	2-38V	84%	<0.5W	-20...45℃	90℃	127x35x20mm
			13W	500mA	2-26V	82%	<0.5W	-20...45℃	90℃	127x35x20mm
			13.2W	600mA	2-22V	81%	<0.5W	-20...45℃	90℃	127x35x20mm
			13.3W	700mA	2-19V	81%	<0.5W	-20...45℃	90℃	127x35x20mm
EUM-25D TW	220-240V	0.95	10.9W	260mA	10-42V	84%	<0.5W	-20...45℃	90℃	137x44x22mm
			14.7W	350mA	10-42V	86%	<0.5W	-20...45℃	90℃	137x44x22mm
			16.8W	400mA	10-42V	86%	<0.5W	-20...45℃	90℃	137x44x22mm
			18.9W	450mA	10-42V	86.5%	<0.5W	-20...45℃	90℃	137x44x22mm
			21W	500mA	10-42V	86.5%	<0.5W	-20...45℃	90℃	137x44x22mm
			23W	550mA	10-42V	86.5%	<0.5W	-20...45℃	90℃	137x44x22mm
			25.2W	600mA	10-42V	86.5%	<0.5W	-20...45℃	90℃	137x44x22mm
			26.6W	700mA	10-38V	86%	<0.5W	-20...45℃	90℃	137x44x22mm
EUM-45D TW	220-240V	0.95	29.4W	700mA	10-42V	89%	<0.5W	-20...45℃	90℃	137x44x28mm
			33.6W	800mA	10-42V	89%	<0.5W	-20...45℃	90℃	137x44x28mm
			37.8W	900mA	10-42V	89%	<0.5W	-20...45℃	90℃	137x44x28mm
			42W	1000mA	10-42V	89%	<0.5W	-20...45℃	90℃	137x44x28mm
			44.1W	1050mA	10-42V	89%	<0.5W	-20...45℃	90℃	137x44x28mm
			45.6W	1200mA	10-38V	88%	<0.5W	-20...45℃	90℃	137x44x28mm
			45.5W	1300mA	10-35V	88%	<0.5W	-20...45℃	90℃	137x44x28mm
			44.8W	1400mA	10-32V	87%	<0.5W	-20...45℃	90℃	137x44x28mm
